Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel-twin
  • Capacity:
    1200 cc
  • Bore:
    3.8 in
  • Stroke:
    3.1 in
  • Compression:
    11 :1
  • Max Power:
    66.2 kW / 7000 rpm
  • Max Torque:
    81.1 ft-lb / 4250 rpm
  • System:
    Ride by wire, multipoint sequential electronic fuel injection
  • Exhaust:
    Brushed 2 into 2 exhaust system with brushed high level silencers
  • Final Drive:
    X ring chain
  • Clutch:
    Wet, multi-plate assist clutch
  • Gearbox:
    6-speed
• Chassis

  add remove
  • Frame:
    Tubular steel
  • Swingarm:
    Twin-sided, aluminium
  • Front Wheel:
    Tubeless 36-spoke 21 x 2.15in, aluminium rims
  • Rear Wheel:
    Tubeless 32-spoke 17 x 4.25in, aluminium rims
  • Front Tyre:
    90/90-21
  • Rear Tyre:
    150/70 R17
  • Front Suspension:
    Marzocchi™ 45mm 1 1 forks, fully adjustable. 250mm wheel travel
  • Rear Suspension:
    Marzocchi twin RSU’s with piggyback reservoir, fully adjustable. 250mm wheel travel
  • Front Brake:
    Twin 320mm Brembo discs, Brembo M4.30 4-piston radial monobloc calipers, ABS
  • Rear Brake:
    Single 255mm disc, Brembo 2-piston floating caliper, ABS
• Dimensions & Weights

  add remove
  • Width Handlebars:
    35.6 in
  • Height Without Mirror:
    49.2 in
  • Seat Height:
    34.3 in
  • Wheelbase:
    61.8 in
  • Rake:
    26.9 º
  • Trail:
    5.1 in
  • Tank Capacity:
    4.0 gal
  • Wet Weight:
    230 kg
